Its automatic installation creates ribbons to run the functions (ribbon Plug-ins > X-Tools). This input method can handle some properties which differ on the individual sheets (Sheet format, base scale, etc.). If the title block prompt and the settings prompt do not match, the particular property will not be filled in. For this method you need to set the input prompt in the Settings dialog. The second method is a text field with a title block prompt. If you want to force creating these properties, check the option "Create property if needed" in the Settings dialog (it will be created automatically on the first save of the document). Only the existing properties are filled by default. The first one are custom properties similar to the iProperty tool. There are two methods for filling in the values.
#XTOOLS SCALE FREE#
It is also available in a free version X-Tools LT. It also adds other useful functions to make designing in Inventor more effective.
#XTOOLS SCALE SERIES#
It adds a series of automatically updated properties (iProperty fields) into the document (drawing) environment. The plug-in application CAD Studio Inventor Tools (X-Tools) makes the most popular iProperty tools available in Autodesk Inventor 2013/2014, 2015/019/2020, and first of all it extends this functionality. Inventor Tools (X-Tools) add-on application for Inventor CAD Studio - Inventor Tools (XTools) Extension and productivity tools for Autodesk Inventor
